2pcs / 6pcs DC 1.8-12V Motor Speed Regulator 1803BK 1803B Low Voltage Controller For Tools

Label:Yes [Wide Motor Application] Suitable for DC 1.8 V, 3 V, 5 V, 6 V, 7.2 V, 12 V, 2 A, 30 W low voltage DC motors. Used in mechanical experiments, industrial automation, and other tasks. [Self Recovery Overcurrent Guard] When current is too high, the guard automatically disconnects. After cooling, it automatically recovers for continued use. [Compact Voltage Range] Input voltage 2.2 V to 12 V DC, output voltage 1.8 V to 12 V DC, continuous output current up to 2 A. Size 32 x 32 x 14 mm / 1.25 x 1.25 x 0.55 in.

[Important Usage Notes] Do not use a supply above 12 V. The governor has a 2 A current limit and cannot drive a continuous current greater than 0.5 A. Connect 1.8 V to 12 V DC to the circuit and confirm correct connection. Do not connect directly to a household 220 V AC supply.

[Easy Speed Control] Equipped with a speed control knob for easy adjustment. Simply turn the knob for precise speed control.

Specification: Item Type: Motor Speed Controller Material: PCB Color:Green Working Current: Under 2A Size: Approx. 32mm * 32 * 14mm / 1.3 * 1.3 * 0.6in Weight: Approx. 13.4g / 0.47oz

Package list: 2pcs :2 * Motor Speed Controller 6pcs :6 * Motor Speed Controller Notes: 1. DC motor governor connected to dc power supply, not directly connected to household 220V AC. 2. This is motor speed controller with maximum current 2A, continuous current greater than 0.5A, 775 motor, the motor of the young's car is not movable. 3. It is not recommended to supply more than 12V, such as 12V battery, which may cause governor damage. 4.Please note that the new type and old type of this product will be sent randomly, and make sure you will not mind before ordering.
