PWM LED Dimmer DC 5-24V 5A Flicker-Free Touch Button Memory Function Built in Constant Voltage Circuit for LED Strip/COB Light

Quantity : 1 High-concerned chemical : none Package : SMD is_d : Yes Supply Voltage : DC 5-24V Type : Module Origin : Mainland China Condition : New

Features 1. Supports DC 5-24V input, compatible with various power environments 2. Utilizes pulse width modulation technology for smooth brightness adjustment 3. Built-in constant voltage circuit extends LED strip lifespan 4. Tactile button design ensures easy operation and responsive actuation 5. Compatible with DC LEDs, COB strips, light bars, and light panels Parameter Input Voltage: Constant-voltage switching power supply, applicable between DC 5V-24V Output Voltage: Constant voltage output, maximum output equals input voltage Output Power: Load capacity up to 5A Operation Mode: Pulse Width Modulation (PWM) dimming Frequency: 23KHz (230kHz switching frequency, flicker-free for eye protection) Load Requirement: Constant voltage output (not constant current); LED strips/panels must use resistor-current-limited drivers Stepless Mode: - Default off at power-on - Short press: On/Off - Long press: Stepless brightness adjustment Resumes last brightness setting upon subsequent power-on Note This control board is designed for DC switching power supply operation. Standby static power consumption is approximately 1-2mA (including indicator lights). It is unsuitable for long-term standby operation with lithium batteries. If using lithium batteries, install a mechanical switch to disconnect power when not in use. Package include Module*1
